Working area: 1000*600mm
100W Reci CO2 laser tube
Step motors and lead shine drivers
Imported lens and mirrors
Shanghai Fulong belt
Honeycomb& Blade working table
X,Y PMI linear guide rail Redpoint
ACO-005 air pump/550W
Exhaust fan/water chiller CW5200
RDCAM 6445G control system
Up-down table and autofocus
Working voltage: 220V 1PH 50HZ
The Laser Machine Technology integrates two laser sources – CO2 and fiber – in one machine, allowing a variety of different materials to be processed in one operation. The CO2 laser source is ideally suited for engraving and cutting plastics, wood, rubber, leather, and many other materials. The fiber laser is the right tool for marking metals and staining plastics.
The characteristic feature of the patented function: Depending on the material, the two laser sources are activated alternately – in one job, without manual changing of the laser tube, lens or focus. The laser sources are easily assigned at the touch of a button in the software. Every conceivable CO2 laser application, as well as an annealing marking or a metal engraving, can be produced in no time. This guarantees that you’ll save time and have more flexibility in everyday work allowing you to grow your business.
